SKU BVX900LI-GR Categories , , Tags , , ,
Overview
Lead time Usually in Stock



Main
input voltage 230 V AC 1 phase
Main Output Voltage 230 V AC 1 phase
Rated power in W 480 W
Rated power in VA 900 VA
Input Connection Type Schuko
nb of power socket outlets 2 Schuko
Cable length 1.22 m
Number of cables 1
Battery type Lead-acid battery
Provided equipment User manual



General
Max runtime 120 min
Number of power module Free slots 0
Number of power module Filled slots 0
Redundant No
UPS size WS



Physical
Color Black
Height 16 cm
Width 12 cm
Depth 35.5 cm
Net weight 6 kg
Mounting support Floor
Mounting preference No preference
Mounting mode Not rack-mountable
Two post mountable 0
USB compatible No



Input
Network frequency 50/60 Hz +/- 5 Hz auto-sensing
Input voltage limits 140…300 V 230 V AC
cos phi 0.53



Output
Maximum Configurable Power in W 480 W
Output frequency 50/60 Hz +/- 1 Hz sync to mains
UPS type Line interactive
Wave type Stepped approximation to a sinewave
Full load runtime 00:01:00 480 W
Graph display 1
Half load runtime 00:06:30 240 W
Maximum configurable power in VA 900 VA
Transfer time 6 ms typical: 10 ms maximum



Conformance
product certifications CE
CB
Equipment protection policy Lifetime: 50000 euros



Environmental
Ambient air temperature for operation 0…40 °C
Relative humidity 0…95 % non-condensing
Operating altitude 0…3000 m
Ambient air temperature for storage -15…40 °C
Storage Relative Humidity 0…95 % non-condensing
Storage altitude 0…3000 m
Acoustic level 40 dBA
IP degree of protection IP20



Batteries & Runtime
Run Time View Runtime Graph



Efficiency View Efficiency Graph



Number of batteries filled slots 0
Number of battery free slots 0
Battery recharge time 8 h
Battery voltage 12 V
Battery capacity 9.0 Ah
Battery life 2…3 year(s)
Replacement battery RBC17
Extended runtime 0



Communications & Management
Control panel LED Status display with on line: on battery
Alarm Alarm when on battery: distinctive low battery alarm



Surge Protection and Filtering
Surge energy rate 273 J



Packing Units
Package 1 Weight 6.5 kg
Package 1 Height 25 cm
Package 1 width 19.7 cm
Package 1 Length 43 cm
SCC14 10731304404597



Contractual warranty
Warranty 2 years repair or replace
